All of our products at Grolltex are fabricated and packaged in a Class 1000 cleanroom. Adhering to our strict procedures and processes allow us to achieve high-yield, high-quality CVD graphene production, the result of which is exceptional graphene quality at an affordable price. Every graphene-coated custom substrate comes with optical images of the graphene on the substrate when possible.
Graphene Coverage: 100% with sporadic adlayers (see optical image above)
FET mobility*: >2700 cm2/(V∙s)
Sheet resistance*: 430 ± 50 Ω/sq
Grain size: >80 μm
Raman D/G ratio*: Indistinguishable to 0.03
Substrates are customer provided and can vary widely. The specific graphene adhesion characteristics cannot be known for all customer substrates; as such, graphene transfer onto custom substrates is conducted on a best-effort basis and results may vary. Please contact us to discuss the properties of the substrate in question. GrollTex will not share any custom substrate information (data, images, designs, etc.) with any entity other than the provider of said substrate(s).
Do you need assistance with Raman measurements on your custom/modified graphene sample? We can help! Please inquire at firstname.lastname@example.org or call (858) 368-9065 for details.
“*The indicated product metrics are generic to our process. Each graphene unit sold is accompanied by a specification sheet unique to the S/N and contains batch-specific metrics. This eliminates guesswork and ensures that you only get the best, well-characterized, and QA-passed graphene.
Data files for mobility and Raman measurements are available upon request. Please send an email including your name, institution, and product serial number to email@example.com and indicate which file(s) you would like.
Please keep the product serial number you receive with your sample, as it will assist us if you have inquiries about the product. The serial number (S/N) is located on the clear plastic container the graphene arrives in, the external silver bag, and your packing list.
If you are planning to perform any patterning or post-processing on your wafer, it is recommended that you perform a wafer conditioning step no more than 12 hours prior to post-processing. Please contact us for recommendations that suit your substrate material.
Do you have more specific questions about our products? Do you have inquiries about custom or bulk orders? Do you need help with Raman measurements of graphene? Please feel free to send us an email at firstname.lastname@example.org, or call us at (858) 368-9065.
