|Graphene Coverage: >100% with sporadic adlayers (see optical image above)||Type/Doping: P/B|
|FET mobility*: >2700 cm2/(V∙s)||Wafer Thickness : 675 +/– 25 μm|
|Sheet resistance*: 430 ± 50 Ω/sq||Oxide Thickness: 300 nm|
|Grain size: >40 μm||Resistivity: 1 – 10 (ohm-cm)|
|Raman D/G ratio: Indistinguishable to 0.03||Orientation: <1-0-0>|
|Growth Method: CZ|
|Metal Impurities: 1.00e10 – 5.00e10 (at/cm2)Substrate|
*The indicated product metrics are generic to our process. Each graphene unit sold is accompanied by a specification sheet unique to the S/N and contains batch-specific metrics. This eliminates guesswork and ensures that you only get the best, well-characterized, and QA-passed graphene.
Data files for mobility and Raman measurements are available upon request. Please send an email including your name, institution, and product serial number to firstname.lastname@example.org and indicate which file(s) you would like.
Do you have more specific questions about our products? Do you have inquiries about custom or bulk orders? Do you need help with Raman measurements of graphene? Please feel free to send us an email at email@example.com, or call us at (858) 368-9065.
